Medical Open Frame

PM1100

Introduction

The PM1100 series of AC-DC switching power supplies in a package of 5.91 x 9.25 x 2.4 inches are capable of delivering 1100 watts of continuous power. The units are constructed on a printed circuit board with an enclosed format for mechanical support and heat sinking. They are designed for medical applications including those needing BF rated insulation and/or an operation altitude up to 5000 meters.

Feature

  • BF Class insulation
  • Operation altitude up to 5000 meters
  • Compact size 5.91” x 9.25” x 2.4”
  • Less than 300 μA leakage current
  • EN55011 Class B conducted emissions
  • Inhibit - TTL low to disable output
  • Standard PS Off and DC OK signals
  • High Efficiency 89% typical
  • Compliant with RoHS requirements
  • Standby output 5 VDC at 200 mA
  • Variable speed internal fan
  • Overvoltage protection
  • Overcurrent protection
  • Thermal protection
PM1100 product picture
RoHS CE
cULus 60601-1 TÜV EN 60601-1 cULus 62368-1 TÜV EN 62368-1



Output

Model

V1

Min.

Current

Max.

Current

Peak

Current

Tol.

Ripple &

Noise

Max. Output

Power

PM1100-14C

24 V

0 A

45.84 A

52.10 A

±2%

240 mV

1100 W /1250 W

PM1100-15C

28 V

0 A

39.29 A

44.65 A

±2%

280 mV

1100 W /1250 W

PM1100-16C

32 V

0 A

34.38 A

39.07 A

±2%

320 mV

1100 W /1250 W

PM1100-17-1C

34 V

0 A

32.35 A

36.77 A

±2%

340 mV

1100 W /1250 W

PM1100-17C

36 V

0 A

30.56 A

34.73 A

±2%

360 mV

1100 W /1250 W

PM1100-18-1C

42 V

0 A

26.20 A

29.77 A

±2%

420 mV

1100 W /1250 W

PM1100-18C

48 V

0 A

22.92 A

26.10 A

±2%

480 mV

1100 W /1250 W
