Medical Adapter

PMP65

Introduction

The PMP65 series of AC/DC switching power supplies are for 65 watts of continuous output power. They are enclosed in a 94V-0 rated polycarbonate case with an IEC320/C6 or IEC320/C8 inlet to mate with interchangeable cord for world-wide use. All models meet EN55011 and FCC class B emission limits, and are designed for medical applications.

Feature

  • High efficiency
  • Low safety ground leakage current
  • Wide input range 85 to 265 VAC
  • 100% burn-in
  • Overvoltage protection
  • Over-temperature protection
  • Short-circuit protection
  • Compliant with CEC and Energy Star Efficiency level V requirements
  • No load power consumption less than 0.5 W
  • Average active efficiency greater than 87%
  • Compliant with RoHS requirements
PMP65 product picture
RoHS CE Energy Star V
cULus ES 60601-1 TÜV EN 60601-1

Model

Output

Average Active Efficiency (typical) @ 115 / 230 Vac

Class I

Class II

V1

Min.

Current

Max.

Current

Tol.

Ripple & Noise

Max.

Power

PMP65S-12

PMP65SF-12

12.0 V

0 A

5.42 A

±5%

120 mV

65 W

87 /88%

PMP65S-13

PMP65SF-13

15.0 V

0 A

4.34 A

±5%

150 mV

65 W

89 /89%

PMP65S-13-1

PMP65SF-13-1

18.0 V

0 A

3.62 A

±5%

180 mV

65 W

87 /88%

PMP65S-13-2

PMP65SF-13-2

19.0 V

0 A

3.43 A

±5%

190 mV

65 W

88 /89%

PMP65S-13-3

PMP65SF-13-3

20.0 V

0 A

3.25 A

±5%

200 mV

65 W

88 /89%

PMP65S-14

PMP65SF-14

24.0 V

0 A

2.71 A

±5%

240 mV

65 W

88 /90%

Download

Name Update Time File Size
file type icon PMP65(20210106) 2024-03-29 306.12 KB
