Industrial Open Frame
PU350
Introduction
The PU350 series of AC-DC switching power supplies in a package of 3 x 5 x 1.28 inches are capable of delivering 350 watts of continuous power at 16.8 CFM forced air cooling or 200 watts at convection cooling. The units are constructed on a printed circuit board. They are designed for ITE, telecommunication, audio/video and industrial applications.
Feature
- 90-264 VAC input with active PFC
- Operation altitude up to 5000 meters
- EN55032 Class B conducted emissions
- Power consumption less than 0.5W
- Compliant with RoHS requirements
- Certified to IEC/EN/UL/CSA 62368-1
|
Model |
Output |
Efficiency (typical) 115 /230 Vac |
||||||
|
V1 |
Min. Current |
Max. Current at convection |
Max. Current at 30 CFM |
Tol. |
Ripple & Noise |
Max. Output Power |
||
|
PU350-12A |
12 V |
0 A |
16.7 A |
29.2 A |
±3% |
150 mV |
200 W /350 W |
87 /91% |
|
PU350-13-1A |
18 V |
0 A |
11.1 A |
19.5 A |
±2% |
234 mV |
200 W /350 W |
88 /91% |
|
PU350-14A |
24 V |
0 A |
8.3 A |
14.6 A |
±2% |
240 mV |
200 W /350 W |
88 /92% |
|
PU350-19A |
54 V |
0 A |
3.7A |
6.5 A |
±2% |
540 mV |
200 W /350 W |
89 /91% |
