Industrial Adapter
PUP60N1
Introduction
The PUP60N1 series of AC/DC switching power supplies are for 60 watts of continuous output power. They are enclosed in a 94V-0 rated polycarbonate with an IEC320/C14 inlet to mate with interchangeable cord for world-wide use. All models meet EN55032 and FCC class B emission limits, and are designed for ITE applications, and comply with UL, CSA, IEC and CE requirement.
Feature
- Operation altitude up to 5000 meters
- Optional output connectors
- Optional on /off switch
- Wide input range 90-264 VAC
- Input surge current protection
- Overvoltage protection
- Overcurrent protection
- Compliant with DoE Efficiency level VI requirements
- 100% burn-in
- ompliant with RoHS requirements
- Meet LPS requirement
- Certified to IEC/EN/UL/CSA 62368-1
|
Model |
Output |
Average Efficiency (typical) @ 115 / 230 Vac |
|||||
|
V1 |
Min. current |
Max. current |
Tol. |
Ripple & Noise(1) |
Max. Power |
||
|
PUP60N1-13 |
13-17 V |
0 A |
4.62 A |
±5% |
130-170 mV |
60 W |
88 /89% |
|
PUP60N1-13-1 |
17-21 V |
0 A |
3.53 A |
±5% |
170-210 mV |
60 W |
89 /90% |
|
PUP60N1-14 |
21-27 V |
0 A |
2.86 A |
±5% |
210-270 mV |
60 W |
88 /89% |
|
PUP60N1-16 |
27-33 V |
0 A |
2.23 A |
±3% |
270-330 mV |
60 W |
88 /89% |
|
PUP60N1-17 |
33-39 V |
0 A |
1.82 A |
±3% |
330-390 mV |
60 W |
88 /89% |
|
PUP60N1-18 |
46-50 V |
0 A |
1.31 A |
±3% |
460-500 mV |
60 W |
89 /89% |
