PUP180N3 | PROTEK

Industrial Adapter

PUP180N3

Introduction

The PUP180N3 series of AC/DC switching power supplies are for 180 watts of continuous output power. They are enclosed in a 94V-0 rated plastic case with an inlet of the IEC320/C14 or IEC320/C6 to mate with interchangeable cord for world-wide use. All models meet EN55032 and FCC class B emission limits, and comply with UL, CSA, IEC and CE requirements.

Feature

  • No load power consumption less than 0.15 W
  • Compliant with DoE level VI requirements
  • Meet Energy Star EPS2.0 /ErP EC No 278/2009 (Lot 7)
  • Meet EU CoC EPS V5 Tier 2
  • Operating altitude up to 5000 meters
  • Overvoltage protection (latch)
  • Short-circuit protection (auto-recovery)
  • Overpower protection (auto-recovery)
  • Over temperature protection (latch)
  • High Efficiency ≧89%
  • With PFC circuit
  • 100% burn-in at full rated load
  • Compliant with RoHS requirements
  • Certified to IEC/EN/UL/CSA 62368-1
PUP180N3 product picture
DoE Level VI RoHS CE
cULus 62368-1 TUV EN 62368-1



Model

Output

Average Active Efficiency (typical)

 @ 115 / 230 Vac

V1

Min. Current

Max. Current

Tol.

Ripple & Noise

Max. Power

PUP180N3-13-2

19 V

0 A

9.47 A

±5%

350 mV

180 W

89 /91%

PUP180N3S-13-2

19 V

0 A

9.47 A

±5%

350 mV

180 W

89 /91%

PUP180N3-14

24 V

0 A

7.50 A

±5%

350 mV

180 W

90 /92%

PUP180N3S-14

24 V

0 A

7.50 A

±5%

350 mV

180 W

90 /92%

PUP180N3-19

54 V

0 A

3.34 A

±5%

350 mV

180 W

91 /93%

PUP180N3S-19

54 V

0 A

3.34 A

±5%

350 mV

180 W

91 /93%



Download

Name Update Time File Size
file type icon PUP180N3(20191007) 2024-03-28 446.32 KB
