Medical Adapter

PMP60N1

Introduction

The PMP60N1 series of AC/DC switching power supplies are for 60 watts of continuous output power. They are enclosed in a 94V-1 rated polyphenylene-oxide case with an IEC320/C14 inlet to mate with interchangeable cord for world-wide use. All models meet EN55011, EN55022 and FCC class B emission limits, and are designed for medical and ITE applications.

Feature

  • Operation up to 5000 meters
  • Optional on /off switch
  • Optional output connectors
  • 100% burn-in
  • Wide input range 90-264 VAC
  • Input surge current protection
  • Overvoltage protection
  • Overcurrent protection
  • Over-temperature protection
  • Compliant with DoE Efficiency level VI requirements (except PMP60N1-12)
  • Compliant with RoHS requirement
PMP60N1 product picture
DoE Level VI RoHS CE
cULus ES 60601-1 TÜV EN 60601-1 cULus 62368-1 TÜV EN 62368-1

Model

Output

Average Active

Efficiency (typical)

@ 115 / 230 Vac

V1

Min.

current

Max.

current

Tol.

Ripple &

Noise(1)

Max. Output

Power

PMP60N1-12

11-13 V

0 A

5.46 A

±5%

110-130 mV

60 W

88 /88%

PMP60N1-13

13-17 V

0 A

4.62 A

±5%

130-170 mV

60 W

88 /89%

PMP60N1-13-1

17-21 V

0 A

3.53 A

±5%

170-210 mV

60 W

89 /90%

PMP60N1-14

21-27 V

0 A

2.86 A

±5%

210-270 mV

60 W

88 /89%

PMP60N1-16

27-33 V

0 A

2.23 A

±3%

270-330 mV

60 W

88 /89%

PMP60N1-17

33-39 V

0 A

1.82 A

±3%

330-390 mV

60 W

88 /89%

PMP60N1-18

46-50 V

0 A

1.31 A

±3%

460-500 mV

60 W

89 /89%

Download

Name Update Time File Size
file type icon PMP60N1(20190102) 2019-05-20 236.85 KB
