Medical Adapter

PMP30

Introduction

The PMP30 series of AC/DC wall mount switching power supplies are for 20-30 watts of continuous output power. They are enclosed in a 94V-0 rated polycarbonate case. The PMP30M models are shipped with a selected interchangeable AC plug, and additional types of AC plug can be purchased from the factory. All models meet EN55011 and FCC class B emission limits, and are designed for medical applications.

Feature

Operation altitude up to 5000 meters
BF class insulation
Interchangeable AC plugs for PMP30M models
Meet IP22 (except PMP30M models)
Overvoltage protection
Over-temperature protection
Short-circuit protection
100% burn-in at full rated load
Compliant with DoE efficiency level VI requirements
Compliant with RoHS requirements

Model			Output						Average Active Efficiency (typical) @ 115 / 230 Vac
Model			V1	Min. Current	Max. Current	Tol.	Ripple & Noise	Max. Output Power
PMP30M-10-A	PMP30NP-10	PMP30E-10	5 V	0 A	4.00 A	±5%	100 mV	20 W	83.5 /83.5%
PMP30M-11-A	PMP30NP-11	PMP30E-11	9 V	0 A	3.00 A	±5%	100 mV	27 W	87.0 /87.0%
PMP30M-11-1-A	PMP30NP-11-1	PMP30E-11-1	10 V	0 A	2.70 A	±5%	100 mV	27 W	87.0 /87.0%
PMP30M-12-A	PMP30NP-12	PMP30E-12	12 V	0 A	2.50 A	±5%	120 mV	30 W	87.5 /87.5%
PMP30M-13-A	PMP30NP-13	PMP30E-13	15 V	0 A	2.00 A	±5%	150 mV	30 W	87.5 /87.5%
PMP30M-13-1-A	PMP30NP-13-1	PMP30E-13-1	18 V	0 A	1.67 A	±5%	180 mV	30 W	87.5 /87.5%
PMP30M-14-A	PMP30NP-14	PMP30E-14	24 V	0 A	1.25 A	±5%	240 mV	30 W	87.5 /87.5%
PMP30M-16-A	PMP30NP-16	PMP30E-16	30 V	0 A	1.00 A	±5%	300 mV	30 W	87.5 /87.5%
PMP30M-18-A	PMP30NP-18	PMP30E-18	48 V	0 A	0.63 A	±5%	480 mV	30 W	87.5 /87.5%
