Medical Adapter

PMP150

Introduction

The PMP150 series of AC/DC switching power supplies are for 132-150 watts of continuous output power. They are enclosed in a 94 V-0 rated polyphenylene-oxide case with an IEC320/C14 or IEC320/C18 inlet to mate with interchangeable cord for world-wide use. All models meet EN55011 and FCC class B emission limits, and are designed for medical applications.

Feature

  • Low safety ground leakage current
  • Wide input range 90 to 264 VAC
  • Optional output connectors
  • 100% burn-in
  • Overvoltage protection
  • Over-temperature protection
  • Overcurrent protection
  • Compliant with CEC and Energy Star Efficiencylevel V requirements (except PMP150-12 and PMP150-13 to level IV)
  • No load power consumption less than 0.5 W
  • Average active efficiency ≧87%
  • Compliant with RoHS requirements
PMP150 product picture
RoHS CE
cULus ES 60601-1 TÜV EN 60601-1

Model

Output

Average Active Efficiency (typical)

@ 115 / 230 Vac

Class I

Class II

V1

Min. Current

Max. Current

Ripple & Noise

Max. Power

PMP150-12

PMP150F-12

12.0 V

0 A

11.00 A

120 mV

132 W

87 /86%

PMP150-13

PMP150F-13

15.0 V

0 A

9.00 A

150 mV

135 W

87 /86%

PMP150-13-2

PMP150F-13-2

19.0 V

0 A

7.90 A

190 mV

150 W

88 /88%

PMP150-14

PMP150F-14

24.0 V

0 A

6.25 A

240 mV

150 W

88 /88%

PMP150-15

PMP150F-15

27.0 V

0 A

5.56 A

270 mV

150 W

89 /88%

PMP150-18

PMP150F-18

48.0 V

0 A

3.13 A

480 mV

150 W

88 /88%

Download

Name Update Time File Size
file type icon PMP150_datasheet 2019-05-21 264.78 KB
